Brief Introduction
eslTAGS SuperGlaxay Series, independently designed by eslTAGS, are utilising the latest Bluetooth® Low Energy 5.0 Technology. STag116 features the latest e-ink display technology, providing fully graphic display, agile & flexible information updates. Also, it delivers a near 180° viewing angle for excellent readability.
Specifications
Material: ABS+PC
Color: White
Dimension: 272 * 196 * 14 mm
Display Technology:EPD
Screen size:11.6-inch
Display Area: 245*163mm
Resolution:960* 640px
Pixel Density:100 dpi
Weight: 416g
Battery Lifetime:5 Years (5 updates/day)
Fixing Ways: Bracket/Ice Plug/Shelf Rail etc.
Display Color: STag116R-Black/White/Red, STag116Y-Black/White/Yellow, STag116B-Black/White
Technical Parameter
Communication Protocol: Bluetooth Low Energy 5.0
Battery: CP783970*1/Rechargeable battery(Optional)
Transmitting Distance: 30-60 Meters
Working Humidity: 50+20%RH
Operating Temperature: 0°C-50°C
Storage Temperature: -20°C-60°C
Compliance
Certification:BQB/FCC/CE/ROHS
Highlight
Updating in seconds
5-year battery lifetime (5 updates/day)
REST API
LED location indicator
Manage by Cloud/APP
NFC Optional
FCC Requirement
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentialinstallation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interferencewill not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turn- ing the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that towhich the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
